Audio-Technica
Kontrollenhet, 100 DU, digital, 4 kanalers inspelning,
Artikelnr:ATUC-50CU
Tillverkarens artikelnr:ATUC-50CUEU
EAN:5055145748510
Fråga ett proffs!
Kim Lindberg
+46(0)10-188 25 62
kim@audiovision.se
Whatever your conferencing or discussion needs, the ATUC-50 is designed to offer reliable, clear and intelligible communication to significantly increase meeting efficiency and effectiveness. Voice is the quickest and most efficient tool for exchanging ideas - whether in meeting rooms, councils, classrooms or through videoconference, speech is the most direct way of communication and understanding.Advanced configuration can be used to tailor the system to the users’ needs. Each configuration can be saved and recalled instantly. Multiple modes allow for adaption to each and every situation including: Free Talk, Request to Talk, Full Remote various override settings: ‘LIFO’, ‘FIFO’ and ‘Non Override’ manual or voice activation and flexible ‘Mic On trigger mode’. IP Control allows full parameter access from most third party control systems. Three Interpretation channels answer today’s need in contemporary meeting rooms.Features of the ATUC-50CU control unit include:
| Control Unit | |
|---|---|
| Dynamic range | 110 dB A-weighted |
| Frequency response | + 1.0, – 2.0dB, 20Hz-20kHz, refer to +4dBu output @ 1kHz |
| Recording | Via USB storage device: 1/2/3/4 track (WAV) (BWF standard) 1/2 track (MP3) (Original format) MP3 bit rate: 64kbps/128kbps/192kbps/256kbps/320kbps |
| Connections | Mic/Line ࡨ, AUX (ST) ࡧ, INTERPRETATION RETURN ࡨ Outputs: Balanced ࡪ, Unbalanced ࡧ LINK /CHAIN : DU A/B Terminals, CU A/B Terminals (DU C/D Terminals) |
| Signal-to-noise Ratio | 90 dB, A-weighted |
| Signal delays | MIC Input to Output: 1ms DU to CU: 1.2ms |
| Headroom | 20 dB |
| Equivalent Input Noise | Mic/Line 1-2, less than -126dBu, Rs=150 ohm |
| Total harmonic distortion | Less than 0.03% @1kHz unity |
| Crosstalk at 1 kHz | Less than dB |
| Power Supply | AC 100V𞴠V 50/60Hz |
| Phantom Power | DC +48V |
| Power Consumption | 20W ~ 175W (max.) |
| Operating Temperature Range | 0-40° C |
| Operating Humidity | 25-85% |
| Dimensions | 482.6mm x 331.6mm x 44mm |
| Weight | 3.4kg |
| OLED Display | 20x2 Character type, Color: Yellow, Operating life time: 100,000 hours |
| Accessories | AC power cord, Quick Setup Guide x 2, Euroblock connectors x 9, Warranty Sheet |
24 månaders garanti på de flesta produkterna.
60 månaders garanti på utvalda produktserier (ATUC-, ATDM-, ATND- samt Engineered Sound Wired ES9XX).
Livstids garanti på premium live-/studiosortimentet (40-Serien, 50-Serien, Artist Serien och Artist Elite Serien).
*Engineered Sound Wireless (ESW) har 24 månaders garanti.
Utvalda artiklar och tillbehör
