Aver
PTZ Kamera 4K/P60, HDMI, 3GSDI, USB, RJ45, NDI HX3, Svart
Artikelnr:AVR-TR315
Tillverkarens artikelnr:TR315
Fråga ett proffs!
John Frisch
+46(0)10-188 25 78
john@audiovision.se
AI Auto Tracking PTZ Camera
AVer’s new TR315 AI Auto Tracking PTZ Camera extends powerful and dependable Pro AV prowess to users across the spectrum of industries. The TR315 showcases proprietary functions — including Presenter Mode, Zone Mode, and Hybrid Mode tracking — driven by advanced AI processing. Seamlessly blending a 12X Optical Zoom lens, 4K 60 fps resolution, and the finesse of hybrid auto tracking and smooth PTZ operations, it’s already the quintessential choice for broadcasting, streaming, or recording.
Specifications
Camera
Image Sensor
1/2.8” 4K Sony Exmor CMOS
Effective Picture Elements
8 Megapixels
Output Resolutions
4K/60, 4K/59.94, 4K/50, 4K/30, 4K/29.97, 4K/25, 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 1080i/60, 1080i/59.94, 1080i/50, 720p/60, 720p/59.94, 720p/50
Minimum Illumination
0.46 lux (IRE50, F1.6, 30fps)
S/N Ratio
≥ 50 dB
Gain
Auto, Manual
TV Lines
1600 (Center)
Shutter Speed
1/1 to 1/32,000 sec
Exposure Control
Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
White Balance
Auto, Manual, ATW, One Push, Indoor, Outdoor
Optical Zoom
12X
Digital Zoom
12X
Viewing Angles
DFOV : 80.6° (Wide) to 7.7° (Tele)
HFOV : 72.8° (Wide) to 6.7° (Tele)
VFOV : 44.1° (Wide) to 3.8° (Tele)
Focal Length
f = 3.9 mm (Wide) to 46.8 mm (Tele)
Aperture (Iris)
F = 1.6 (Wide) to 2.8 (Tele)
Minimum Working Distance
0.3 m (Wide)
1.5 m (Tele)
Pan / Tilt Angles
Pan : ±170°
Tilt : +90° / -30°
Pan / Tilt Speed (Manual)
Pan : 0.1° to 100° / sec
Tilt : 0.1° to 100° / sec
Preset Speed
Pan : 200° / sec
Tilt : 200° / sec
Preset Positions
10 (IR)
256 (RS-232, RS-422, IP)
Camera Control - Interfaces
RS-232 (DIN8)
RS-422 (RJ45)
IP
USB
Camera Control - Protocols
VISCA (RS-232 / RS-422 / IP)
PELCO-D & PELCO-P (RS-232 / RS-422)
CGI (IP)
USB
ONVIF
Image Processing
Noise Reduction (2D / 3D)
Flip
Mirror
WDR
BLC
Power Frequencies
50 Hz, 60 Hz
AI Auto Tracking Functions
Tracking Modes
Presenter Mode
Zone Mode
Hybrid Mode
Privacy Protection Mechanisms
Protection Mode
Sleep Mode
AI Control Functions
Gesture Control
Yes
Audio
Channels
2ch Stereo
Codecs
AAC-LC (48K)
PCM (8K)
Sample Rates
48 / 44.1 / 32 / 24 / 16 / 8 KHz
Interface
Video Outputs
3G-SDI, HDMI, IP, USB
Audio Outputs
3G-SDI, HDMI, IP, USB
Audio Inputs
MIC in, Line in
General
Power Requirement
AC 100 - 240V to DC 12V/5A
Power Consumption
19W
PoE
PoE+
Dimensions (W x H x D)
180.0 x 192.0 x 145.0 mm
Net Weight
2.0 (±0.1) kg
Application
Indoor
Tally Lamp
Yes
Security
Kensington Slot
Remote Control
Infrared
Operating Conditions
Temperature : 0 °C to +40 °C ; Humidity : 20% to 80%
Storage Conditions
Temperature : -20 °C to +60 °C ; Humidity: 20% to 95%
IP Streaming
Resolution
2160p 60fps
Network Video Compress Formats
H.264, H.265, MJPEG
Network Audio Compress Formats
AAC-LC (48K), PCM (8K)
Maximum Frame Rate
2160p 60fps
Bit-Rate Control Modes
VBR, CBR (selectable)
Range of Bit-Rate Setting
512 Kbps to 32 Mbps
Network Interface
10 / 100 / 1000 Base-T
Multi-Stream Capability**
5
4K 60fps: RTSP, HDMI, USB, & NDI® HX3 / Dante AV-H
1080p 60fps: 3G-SDI
Network Protocols
IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, RTP / RTCP, RTSP, RTMP, SRT, HLS, NDI, LLDP, VISCA over IP
AV over IP Protocols
NDI® HX3 & Dante AV-H
USB
Connector
USB 3.1
Video Formats
MJPEG, YUY2
Audio Format
PCM
Maximum Video Resolution
2160p
USB Video Class (UVC)
UVC 1.1
USB Audio Class (UAC)
UAC 1.0
Web UI
Live Video Preview
Yes
Camera PTZ Control
Pan, Tilt, Zoom, Focus, Preset Control
Camera / Image Adjustment
Exposure, White Balance, Picture
Network Configuration
DHCP, IP Address, Gateway, Subnet Mask, DNS
Supported Web Browsers
Chrome™, Microsoft Edge, Safari®
Software Tools
IP Search and Configuration Tool
Support Windows® 7 or later
Enterprise Management (PTZ Management)
Support Windows® 10 or later
Control Panel
Supports iOS & iPadOS® 11 or later
PTZ Link
Supports Windows® 7 or later, macOS® 10.14 or later
OBS Plugin for PTZ Cameras
Supports Windows® 8 or later, macOS® High Sierra v10.13 or later
CaptureShare
Supports Windows® 7 or later, macOS® 10.14 or later
Room Management (PTZApp 2)
Supports Windows® 7 or later, macOS® 11.6 or later
Cloud Management
Supports Chrome™ & Microsoft Edge browsers
Warranty
Camera
5 Years
Accessories
1 Year
Package Contents
Camera, Remote Control, RS-232 In/Out Cable, Din 8 To D-Sub 9 Cable, Power Adapter, Power Cord, Cable Ties (x 4), M2 x 4 mm Screws (x 3), M3 x 6 mm Screws (x3), 1/4'-20L 6.5mm Screws (x2), Cable Fixing Plate, Ceiling Mount Brackets (x 2), Drilling Paper, Quick Start Guide
Optional Accessories
AVer CL01 PTZ Camera Controller, L-Type Wall Mount
