Aver
PTZ Kamera 4KP60,HDMI, 3GSDI, USB, IP, NDI HX3, Svart
Artikelnr:AVR-PTZ310UV2B
Tillverkarens artikelnr:PTZ310UV2B
Fråga ett proffs!
John Frisch
+46(0)10-188 25 78
john@audiovision.se
AI Auto Tracking PTZ Camera
The PTC310UV2 AI Auto Tracking PTZ Camera makes powerful and reliable Pro AV capability available to everyone. Drawing inspiration from the AVer Professional PTZ Camera family, the PTC310UV2 features in-house AI functions like Presenter Mode, Zone Mode and Hybrid Mode auto tracking, thanks to Human Detection processing. Combine the 12X Optical Zoom lens and 4K resolution with hybrid auto tracking and smooth PTZ functions for broadcasting, streaming, or recording. Your exciting journey of audio and video capturing starts here!
Specifications
Camera
Image Sensor
1/2.8' 4K Exmor CMOS
Effective Picture Elements
8 Megapixels
Output Resolutions
4K/30, 4K/29.97, 4K/25, 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 1080i/60, 1080i/59.94, 1080i/50, 720p/60, 720p/59.94, 720p/50
Minimum Illumination
0.5 lux (IRE50, F1.6, 30fps)
S/N Ratio
≥ 50dB
Gain
Auto, Manual
TV Lines
1400 (Center/Wide)
Shutter Speed
1/1 to 1/32,000 sec
Exposure Control
Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
White Balance
Auto, Manual, ATW, One Push
Optical Zoom
12X
Digital Zoom
12X
Total Zoom
144X
Viewing Angles
DFOV : 78° (Wide) to 7° (Tele)
HFOV : 70° (Wide) to 6° (Tele)
VFOV : 42° (Wide) to 3° (Tele)
Focal Length
f = 3.9 mm (Wide) to 46.8 mm (Tele)
Aperture (Iris)
F = 1.6 (Wide) to 2.8 (Tele)
Minimum Working Distance
0.3 m (Wide), 1.5m (Tele)
Pan / Tilt Angles
Pan : ±170°, Tilt : +90° / -30°
Pan / Tilt Speed (Manual)
Pan : 0.1° to 100° /sec, Tilt : 0.1° to 100° /sec
Preset Speed
Pan : 200° /sec, Tilt : 200° /sec
Preset Positions
10 (IR), 255 (RS-232, RS-422, IP)
Camera Control - Interfaces
RS-232 (DIN8), RS-422 (RJ45), IP
Camera Control - Protocols
VISCA (RS-232 / RS-422 / IP), PELCO-D & PELCO-P (RS-232 / RS-422), CGI (IP)
Image Processing
Noise Reduction (2D / 3D), Flip, Mirror
Power Frequencies
50Hz, 60Hz
AI Auto Tracking Functions
Tracking Modes
Presenter Mode, Zone Mode, Hybrid Mode
Privacy Protection Mechanism
Protection Mode
Sleep Mode
Audio
Channels
2ch Stereo
Codecs
AAC-LC, PCM
Interface
Video Outputs
3G-SDI, HDMI, IP, USB
Audio Outputs
3G-SDI, HDMI, IP, USB
Audio Inputs
MIC in, Line in
General
Power Requirement
AC 100 - 240V to DC 12V/5A
Power Consumption
19W
PoE
PoE+
Dimensions (W x H x D)
180.0 x 192.0 x 145.0 mm
Net Weight
2.0 (±0.1) kg
Application
Indoor
Tally Lamp
Yes
Security
Kensington Slot
Remote Control
Infrared
Operating Conditions
Temperature: 0°C to +40°C ; Humidity: 20% to 80%
Storage Conditions
Temperature: -20°C to +60°C ; Humidity: 20% to 95%
IP Streaming
Resolution
4K 30fps
Network Video Compress Formats
H.264, H.265, MJPEG
Maximum Frame Rate
4K 30fps
Bit-rate Control Modes
VBR, CBR (selectable)
Range of Bit-Rate Setting
512 Kbps to 32 Mbps
Network Interface
10 / 100 / 1000 Base-T
Multi-Stream Capability
3 (RTSP / Web Page / NDI HX), 4K 30fps (max.)
Network Protocols
IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, RTP / RTCP, RTSP, RTMP, VISCA over IP
NDI®|HX Capability
Yes
USB
Connector
USB 3.1
Video Formats
MJPEG, YUY2
Maximum Video Resolution
2160p
USB Video Class
UVC1.1
USB Audio Class
UAC1.0
Web UI
Live Video Preview
Yes
Camera PTZ Control
Pan, Tilt, Zoom, Focus, Preset Control
Camera / Image Adjustment
Exposure, White Balance, Picture
Network Configuration
DHCP, IP Address, Gateway, Subnet Mask, DNS
Software Tools
IP Search & Configuration Tool
Support Windows® 7 or later
Enterprise Management (PTZ Management)
Support Windows® 10 or later
PTZ Control Panel
Supports iOS & iPadOS® 11 or later
PTZ Link
Support Windows® 7 or later, macOS® 10.14 or later
OBS Plugin for PTZ Cameras
Support Windows® 8 or later, macOS® High Sierra v10.13 or later
CaptureShare
Support Windows® 7 or later, macOS® 10.14 or later
Room Management (PTZApp 2)
Supports Windows® 7 or later, macOS® 11.6 or later
Cloud Management
Supports Windows® 7 or later, macOS® 10 or later
Warranty
Camera
5 Years
Accessories
1 Year
Package Contents
Camera, Drilling Paper, Ceiling Mount Bracket (x2) Quick Start Guide, Cable Fixing Plate, M2 x 4 mm Screw (x3), Power Adapter & Power Cord, 1/4'-20 L=6.5 mm Screw (x2), Remote Control, M3 x 6 mm Screw (x3), DIN 8 to D-Sub 9 Cable, RS-232 In/Out Y Cable, Cable Ties (x4)
Optional Accessories
AVer CL01 PTZ Camera Controller, L-Type Wall Mount
36 månaders garanti på samtliga produkter. Garantin kan kostnadsfritt förlängas med ytterligare 24 månader till totalt 60 månader via registrering av produkten. För mer information om Aver's garantipolicy klicka här.
AVer är en global tillverkare av professionella videolösningar med särskilt fokus på utbildning, företagsmöten och hybridkommunikation. Företaget är välkänt för sina innovativa dokumentkameror och videokonferenssystem som kombinerar smart funktionalitet med hög bildkvalitet och enkel användning.
Inom företagssegmentet erbjuder AVer ett brett utbud av certifierade konferenskameror och ljud-/bildsystem för plattformar som Microsoft Teams, Zoom och Google Meet. Produkterna har ofta AI-funktioner som auto-framing, talarspårning och presets – vilket gör dem idealiska för moderna mötesrum, oavsett storlek.
