Distance Learning Tracking Camera
When distance learning and hybrid classrooms are the new normal, the AVer DL30 is a must-have solution for online education. With the DL30 connected to a laptop, you can present freely onstage while livestreaming so students can learn no matter where they are. Teachers don’t need to be camera shy anymore—they can just be themselves and teach how they want thanks to the DL30 tracking camera!

Specifications
Camera
Image sensor
1/2.8' 1080p Low Lux CMOS
Effective Picture Elements
2 Megapixels
Output Resolution
1080p/60 (IP Streaming & USB)
Minimum Illumination
0.5 Lux (IRE50, F1.6, 30fps)
S/N Ratio
> 50 dB
Gain
Auto, Manual
TV Line
800 (Center), 600 (Corner)
Shutter Speed
1/4 to 1/10,000 sec (60 Hz)
1/3 to 1/10,000 sec (50 Hz)
Exposure Control
Auto, Manual, WDR
WDR
Yes
White Balance
Auto, Manual
Optical Zoom
12X
Digital Zoom
2X
Viewing Angles
DFOV : 84.1° (Wide) to 7.8° (Tele)
HFOV : 76.5° (Wide) to 6.8° (Tele)
VFOV : 47.3° (Wide) to 3.8° (Tele)
Focal length
f = 3.9 mm (Wide) to 46.8 mm (Tele)
Aperture (Iris)
F = 1.6 (Wide) to 2.8 (Tele)
Minimum Working Distance
0.3 m (Wide), 1.5 m (Tele)
Pan / Tilt Angles
Pan : ±170°, Tilt : ±90°
Pan / Tilt Speed (Manual)
Pan: 1° to 90°/sec
Tilt: 7.85° to 45°/sec
Preset Speed
Pan : 120° / sec, Tilt : 110.84° / sec
Preset Positions
10 (IR), 256 (IP & USB)
Camera Control - Interface
IP, USB
Camera Control - Protocol
VISCA (IP), CGI (IP), USB
Image Processing
Noise Reduction (2D/3D), Flip, Mirror, WDR
Power Frequency
50Hz / 60Hz

AI Auto Tracking Functions
Tracking Modes
Presenter Mode, Zone Mode, Hybrid Mode

Privacy Protection Mechanisms
Protection Modes
Privacy Mode, Sleep Mode

Audio
Channels
2ch (Stereo)
Codecs
AAC, PCM
Sample Rate
AAC (48, 32, 16, 8 KHz), PCM (48 KHz)

Interface
Video Outputs
IP, USB
Audio Outputs
IP, USB
Audio Inputs
Mic in, Line in

General
Power Requirement
AC 110–220V to DC 12V/2A
Power Consumption
12W
PoE
PoE+
Dimensions (W x H x D)
158.8 x 200.0 x 162.2 mm
Net Weight
1.62 (±0.1) kg
Application
Indoor
Tally Lamp
N/A
Security
Kensington Slot
Remote Control
Infrared
Operating Condition
Temperature: 0°C to 40°C
Humidity: 20% to 80%
Storage Condition
Temperature: -20°C to 60°C
Humidity: 20% to 95%

IP Streaming
Resolution
1080p 60fps
Network Video Compress Formats
H.264, MJPEG (Web Page)
Network Audio Compression Formats
AAC
Sample Rates
48, 32, 16, 8 KHz
Maximum Frame Rate
1080p 60fps
Bit-rate Control Modes
VBR, CBR
Range of Bit-rate setting
512 Kbps to 32 Mbps
Network Interface
10/100 Base-T
Multi-stream Capability
2 (1 for IP Streaming, 1 for Web Page), (1 for USB, 1 for Web Page),1080p 60fps (max.)
3 (1 for IP Streaming, 1 for Web Page, 1 for USB), 1080p 30fps (max.)
Network Protocol
IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, RTP / RTCP, RTSP, RTMP, VISCA over IP
NDI®|HX Capability
N/A

USB
Connector
USB 3.1 Gen 1 Type-B
Video Formats
MJPEG, YUY2
Maximum Video Resolution
1080p
USB Video Class (UVC)
UVC1.1
USB Audio Class (UAC)
UAC1.0

Web UI
Live Video Preview
Yes
Camera PTZ Control
Pan / Tilt / Zoom / Focus / Preset Control
Camera / Image Adjustment
Exposure / White Balance / Picture
Network Configuration
DHCP, IP Address, Gateway, Subnet Mask, DNS
Software Tools
IP Search and Configuration Tool
Supports Windows® 7 or later
Enterprise Management (PTZ Management)
Supports Windows® 10 or later
PTZ Control Panel
Supports iOS & iPadOS® 9 or later
CaptureShare
Supports Windows® 7 or later, macOS® 10.14 or later
PTZ Link
Supports Windows® 7 or later, macOS® 10.14 or later

Warranty
Camera
3 Years
Accessories
1 Year
Package Contents
Camera, Remote Control, Power Adapter, Power Cord, USB Cable, Cable Ties (x4), Cable Fixing Plate (x1), M2 x 4mm Screws (x2), 1/4'-20L 7.5mm Screw (x1), Quick Start Guide
Optional Accessories
Wall Mount Kit (Brackets (x2), M4 x 8mm Screws (x2), 1/4'-20L 7.5mm, Screw (x1), Wall Mount Kit Installation Guide), Ceiling Mount Kit (Brackets (x2), M3 x 6mm Screws (x3), 1/4'-20L 7.5mm, Screws (x3), Ceiling Mount Kit Installation Guide)
